We have our own sales team, design team, technical team, QC team and package team. We have strict quality control procedures for each process. Also, all of our workers are experienced in printing field for 11 Years Factory wholesale Poly-crystalline Solar Panel 3W Slovak Republic Manufacturers, We also ensure that your selection will be crafted with the highest quality and reliability. Please feel free to contact us for further information.


Poly-crystalline Solar Panel 3W

Technical parameter

Maximum Power(W)                        3W

Optimum Power Voltage(Vmp)        9V

Optimum Operating Current(Imp)    0.34A

Open Circuit Voltage(Voc)               10.8V

Short Circuit Current(Isc)                 0.37A

Mechanical Characteristics

Cell Type                              Polycrystalline

No of Cell                                         18 (2x9pcs)

Dimensions                                     145x245x18mm

Weight                                             0.52KGS

Front Glass                                     3.2mm,High Transmission, Low Iron,Tempered Glass

Temperature and Coefficients

Operating Temperature(°C):                -40°C ~ + 85°C

Maximum System Voltage:                  600V(UL)/1000V(IEC) DC

Maximum Rated Current Series:         10A

Temperature Coefficients of Pmax:     -0.435%

Temperature Coefficients of Voc:        -0.35%

Temperature Coefficients of Isc:           0.043%

Nominal Operationg Cell Temperature (NOCT): 47+/-2°C

 Materials of solar panel

1).Solar Cell——Polycrystalline solar cell 156*156mm

2).Front Glass——-3.2mm, high transmission, low iron, tempered glass

3).EVA——-excellent anti-aging EVA

4).TPT——-TPT hot seal made of flame resistance

5).Frame——anodized aluminum profile

6).Junction Box——-IP65 rated, high quality, with diode protection

Superiority: high quality anodized aluminum frame, high efficiency long life, easy installation, strong wind resistance, strong hail resistance.

Features

1. High cell efficiency with quality silicon materials for long term output stability

2. Strictly quality control ensure the stability and reliability, totally 23 QC procedures

3. High transmittance low iron tempered glass with enhanced stiffness and impact resistance

4. Both Poly-crystalline and Mono-crystalline

5. Excellent performance in harsh weather

6. Outstanding electrical performance under high temperature and low irradiance

Quality assurance testing

Thermal cycling test

Thermal shock test

Thermal/Freezing and high humidity cycling test

Electrical isolation test

Hail impact test

Mechanical, wind and twist loading test

Salt mist test

Light and water-exposure test

Moist carbon dioxide/sulphur dioxide
